Input: Universal Input
Output: 9V/2.5A
DC Connector: Universal Size Optional
Minimum Order: 500 Pieces
Lead Time: 15-20 Days
Input Specifications | Output Specifications | |||
Voltage | 90-264VAC | Voltage | 9V | |
Frequency | 47-63Hz | Current | 2.5A | |
Current | 1.5A | Power | 22.5W | |
Safety Approvals | Ripple and Noise | 100mVp-p max | ||
Turn On Time | 15-30mS | |||
Voltage Accuracy | ±3% | |||
Current Accuracy | ±3% | |||
Efficiency | Ⅵ | |||
Product Shell Features | Protections | |||
Flame retardant
Ultrasonic bonding & Whole sealing Small volume & Streamlined Portable |
Short circuit protection
Over voltage protection Over current protection Over temperature protection |
|||
Tests | Environmental Specifications | |||
Hi-pot Test: 3750VAC, 60S, 5mA max
Lightning surge: up to 1000V (accept 3000V) Leakage Current: 0.25mA max Burn-in Test: rate load, 40±3℃, 4 hours |
Operating Temperature | 0-40℃ | ||
Storage Humidity | 5%-95%RH | |||
Storage Temperature | -20~+80℃ | |||
Temperature Coefficient | 0.05%/℃ |
